Ford New Holland 2000, 3000, 3400, 3500, 3550, 4000, 4400, 4500, 5000, 5500, 5550, 7000 Tractor Service Manual 40340070 English

$ 19.99 USD
View More

Brands: Ford / Ford New Holland / New Holland Agriculture

Equipment Type: Tractor (Agricultural & Industrial)

Manuals Type: Service Manual (5-Volume Compendium)

Machine Model & Serial Number: 2000, 3000, 4000, 5000, 7000 (Agricultural); 3400, 3500, 3550, 4400, 4500, 5500, 5550 (Industrial) 1965-1975

Region: N/R

Book Code: 40340070

Issued: Reprinted Edition

Language: English

Pages: 1688

File Format: Portable Document Format (PDF)

Remark: The absolute 1252-page ultimate five-volume service compendium for the complete range of 1965-1975 Ford tractors. Nuclear Level Value: This manual provides exhaustive internal engine overhaul procedures for all gasoline, diesel, and LP-gas engines. Includes complete reconstruction of 3 and 4-cylinder engine blocks, crankshaft regrinding, and balancer rebuilds. Features extreme deep-level data for Select-O-Speed transmissions, Dual Power systems, Load Monitor hydraulics, and professional tractor splitting procedures. Includes the comprehensive 7000 series and 755B supplements. A non-negotiable asset for large-scale repair centers and restoration projects.

Table of contents

  • FOREWORD & SAFETY PRECAUTIONS
    • Manual Structure (Parts 1-17 Agricultural, Parts 18-25 Industrial)
    • Serial Number and Production Code Interpretation (Engines, Transmissions, Rear Axles)
  • NEW MODEL SUPPLEMENTS (Agricultural and Industrial Changes)
    • Engine Systems: Cylinder Head porting, Camshaft lift, and Heavy Duty Connecting Rods
    • Cooling System: Radiator fin density and Tropical options
    • Fuel Systems: New Injector identification and Air Cleaner hose changes
    • Clutches: 13-inch torsion damped disc and release bearng hub hardened faces
    • Transmissions: 7-speed/8-speed housing modifications and Gear shift effort reduction
    • Power Take-Off: Independent P.T.O. operating pressure increase (150-225 psi)
    • Hydraulic Systems: High-pressure relief valve characteristics and shim adjustment
    • Steering Systems: Power Assisted Steering pump with integral reservoir
  • 7000 SERIES SUPPLEMENT
    • Engine System: Turbocharger integration, pistons, and valve interference angles
    • Transmission: Helical gear design and mainshaft taper roller bearings
    • Hydraulic Systems: Load Monitor torque sensing unit operation and adjustment
  • PART 1: ENGINE SYSTEMS
    • Chapter 1: Engines and Lubrication System
      • Internal Overhaul: Cylinder Head, Valves, Guides, and Rocker Gear
      • Timing Gears: Synchronization marks and backlash checks
      • Internal Components: Rods, Bearings, Pistons, Rings, and Cylinder Reconditioning
      • Crankshaft: Main bearings, Flywheel, and Regrinding specifications
      • Turbocharger: Schwitzer and Air Research model complete overhaul
    • Chapter 2: Cooling System (Radiator, Thermostat, and Water Pump rebuild)
    • Chapter 3: Troubleshooting, Specifications, and Special Tools
  • PART 2: FUEL SYSTEMS
    • Gasoline Fuel Systems: Carburetor float system and governor recalibration
    • Diesel Fuel Systems: Minimec and Lucas distributor-type injection pump timing
    • Injectors: Pop-testing, spray pattern cone data, and internal reconditioning
  • PART 3: ELECTRICAL SYSTEMS
    • Wiring Schematics: Full A, B, and C prefix diagrams
    • Battery: Specific gravity tests and fast charging limits
    • Generator and Regulator: 11-amp and 22-amp unit bench tests
    • Starting Motor: 4-1/2 and 5-inch solenoid-operated pre-engaged overhaul
  • PART 4: CLUTCHES (Single and Double Clutch Overhaul with Universal Fixture data)
  • PART 5 & 6: FOUR AND SIX-SPEED TRANSMISSIONS (Power Flow and Internal Gear Train Rebuild)
  • PART 7: SEVEN AND EIGHT-SPEED TRANSMISSIONS (Synchromesh and Dual Power Overhaul)
  • PART 8: SELECT-O-SPEED TRANSMISSION
    • Planetary Gear Power Flow: Ten forward and two reverse speed logic
    • Hydraulic Control: Valve body, servos, and timing valve sequencing
    • Maintenance: Filter element replacement and pressure testing
  • PART 9: POWER TAKE-OFF (Transmission, Live, and Independent P.T.O. Overhaul)
  • PART 10: REAR AXLE AND BRAKES (Planetary Reduction, Differential Lock, and Wet Disc Brakes)
  • PART 11: HYDRAULIC SYSTEMS (Piston/Gear Pump rebuild and Load Monitor calibration)
  • PART 12: STEERING SYSTEMS (Manual and Power Assisted gear/cylinder reconditioning)
  • PART 13: FRONT AXLE (Adjustable and Industrial axle overhaul)
  • PART 14: WHEELS AND TIRES (Power Adjusted Wheels and Liquid Ballasting data)
  • PART 15: SEPARATING THE TRACTOR (Professional Tractor Splitting Procedures)
  • PART 16: ACCESSORIES AND GENERAL (Remote Valves and Belt Pulley overhaul)

Professional Service Insight
This five-volume manual represents the definitive technical reference for Ford tractors produced during the 1965-1975 era. When overhauling the 7000 series, pay critical attention to the 60-degree intake valve seat angle and the specialized Load Monitor torque sensing unit shimming. The Select-O-Speed transmission requires absolute cleanliness; even minute particles can cause hydraulic valve spools to stick. Always ensure that the front axle pin spacer is correctly selected to minimize longitudinal movement. For diesel engines, remember that the fuel injection pump is self-bleeding, but the fuel filters and injectors must be manually primed using the lift pump priming lever.
