Ford New Holland 744 Loader Service Manual 40074410 English
Brands: Ford / Ford New Holland / New Holland Agriculture
Equipment Type: Loader
Manuals Type: Service Manual
Machine Model & Serial Number: Ford Series 744 Loader
Region: N/R
Book Code: 40074410
Issued: Printed in U.S.A.
Language: English
Pages: 54
File Format: Portable Document Format (PDF)
Remark: Complete factory service guide detailing the loader frame, hydraulic systems, pumps, control valves, and double-acting cylinders.
Table of contents
- SAFETY PRECAUTIONS
- SERVICE TECHNIQUES
- DESCRIPTION AND OPERATION
- Loader Frame
- Hydraulic System
- Hydraulic Pump
- Control Valve
- Float Mechanism
- System Relief Valve
- Check Valves
- Anti-Cavitation Valve
- Cylinders
- GENERAL OIL FLOWS
- TROUBLE SHOOTING
- ADJUSTMENTS AND PRESSURE CHECKS
- Hydraulic Tests
- Hydraulic Pump Performance Test
- Cylinder Piston Seal Leakage Test
- COMPONENT OVERHAUL
- Hydraulic Pump
- Loader Frame and Cylinder Bushings
- Lift and Bucket Cylinders
- Control Valve
- LUBRICATION AND MAINTENANCE
- SPECIFICATIONS
- Lift Cylinder
- Bucket Cylinder
- System Hydraulic Capacity
Foreword
This manual contains service information for the Ford Series 744 Loader. Detailed information is provided on description and operation, trouble shooting, tests and adjustments, component overhaul, lubrication and specifications. Instructions for installing the loaders, loader components, or attaching kits are not covered in this manual. Refer to the appropriate Operator's Manual for detailed information. The service procedures in this manual are the most apparent, practical, and efficient methods.
